The Eflite G90 Gyro – Good Performance, Flexibility, & Price

eFlite G90 GyroeFlite G90 Gyro


The Eflite G90 Gyro was a good little sub-micro gyro back in the day for those with smaller 300-450 size electric single rotor RC helicopters. At a third the weight and half the cost of a Futaba GY-401, the little gyro had a lot going for it.


The Eflite G90 Gryo can be used in either Heading Lock mode or Rate Mode. Both modes can be selected by using either the switch on the gyro or remotely on your computerized radio using the remote gyro gain function.

Gain as well can be adjusted on the Eflite G90 gyro by the small adjustment pot for those of you without a computerized radio or of course can be set remotely using the ATV values in your gyro gain menu on your computerized radio.

Since both the gain and modes are selectable on the gyro or remotely, this gyro will work with both non computerized radios and computerized ones. Thus the reason I say it is flexible.

The G90 also allows you to switch between a fast digital output or slower analog output frame rates allowing the use of less expensive tail rotor servos that can’t handle the high frequency rate.

Of course the G90 can be paired up with a super fast digital specific tail rotor servo like the JR-3400G or 3500G that will give very impressive results if your are into 3D. With both built-in drift cancellation and temperature compensation circuitry, the E-flite G90 gyro holds the tail solid throughout the entire flight.

I have seen both the Blade 400 and Trex 450 with the G-90/JR-3400G pairing fly incredible 3D and was amazed at how well the G90 locked the tail in all flight attitudes.

At only 9 grams – this is one of the lightest full function heading lock gyros on the market. Perfect for small sized electrics from 300 size up 450’s. Saving weight on small electrics pays big dividends in flight time and performance.

Bottom Line...

If you are looking at saving both weight and cash on your smaller electric heli; but still want good performance, a solid tail lock, and the flexibility of a gyro that works with both computerized and non computerized radios, the Eflite G90 gyro is hard to beat.


Eflite G90 Gyro Specifications

  • Type: Sub-Micro Heading Hold Gyro
  • Sensor: Piezoelectric Ceramic
  • Weight: 9.0 grams (0.32 oz)
  • Dimensions (WxLxH): 20 x 20 x 15mm (0.8 x 0.8 x 0.6 inches)
  • Gain Setting: Remote or by adjusting pot on gyro
  • Mode Setting: Rate and Heading Hold, both remote or using switch on gyro
  • Operating Voltage: 4.2 – 8.0 VDC
  • Reversing Switch: Yes, on gyro
  • Limit Trimmer: None
  • High/Low Frequency Rate Selectable Switch on Gyro (Analog and Digital Servos Support)

E-FLITE G90 GYRO INSTRUCTION MANUAL
